Product Name:SC-FS03



Keywords:For petroleum, chemistry and paper making single cartridge seal. single cartridge seal



Product Description:SC-FS03 single cartridge seal, For petroleum, chemistry and paper making,medical industry.trisun mechanical seal manufacture,Trisun Mechanical Seal Manufacture Co., Ltd. is the advanced designer & manufacturer of mechanical seal, the range involves in: industrial pump mechanical seal, mixer and agitator seal, cartridge seal, metal bellows seal, auto cooling pump seal and auto air-condition compressor lip seal. Trisun products can replace the mechanical seals produced by John Crane and Burgmann and be widely used in petroleum, chemistry, refinery, paper making, pharmacy, power and auto industry.



OPERATING LIMITS

Temperature:

-40℃~+220℃

Pressure:

≤2Mpa

Speed:

≤23m/s













Rotary Ring:

SiC/TC

Stationary Ring:

SiC/Carbon

Secondary Seal:

VITON/PTFECoatedVITON/PTFE

Other Parts :

SUS304/SUS316/Titanium/Hastelloy-C





d

d1min

d1max

d2

d26

l4

l2

l3

l1

1

1.625

1.875

2.115

3.69-3.75

1.913

1.975

0.212

0.274

1.125

1.75

2

2.24

3.69-3.75

1.913

1.975

0.212

0.274

1.25

1.89

2.245

2.495

4.19-4.25

1.913

1.975

0.212

0.274

1.375

2

2.375

2.615

3.94-4

1.913

1.975

0.212

0.264

1.437

2.25

2.688

2.775

4.72-4.78

1.973

2.035

0.222

0.284

1.5

2.25

2.525

2.775

4.69-4.75

1.973

2.035

0.202

0.264

1.625

2.375

2.78

3.03

4.69-4.75

1.973

2.035

0.202

0.264

1.75

2.5

2.875

3.15

4.94-5

1.973

2.035

0.202

0.264

1.875

2.625

2.875

3.15

4.94-5

1.973

2.035

0.202

0.264

1.937

2.69

2.92

TBD

TBD

1.973

2.035

0.207

0.269

2

2.75

3.03

3.28

5-5.12

1.973

2.035

0.202

0.264

2.125

2.875

3.125

3.43

5.94-6

1.973

2.035

0.202

0.264

2.25

3

3.28

TBD

TBD

1.973

2.035

0.206

0.268

2.375

3.125

3.687

3.975

6.32-6.38

1.973

2.035

0.202

0.264

2.437

3.375

3.45

TBD

6.32-6.38

1.942

2.004

0.233

0.295

2.5

3.375

3.687

3.975

6.32-6.38

1.973

2.035

0.202

0.264

2.625

3.625

4.312

4.615

7.19-7.25

2.726

2.788

0.204

0.266

2.75

3.75

4.312

4.615

7.19-7.25

2.726

2.788

0.204

0.266
